Product characteristics
| Product characteristic | Non Adhesive (NA) | Self Adhesive (SA) |
|---|---|---|
| Item number | 13480 | 13478 |
| Format | 2600x1000x1,5 mm | 2600x1000x1,63 mm |
| Surface material | PU-Leather (Polyurethane synthetic leather) | PU-Leather (Polyurethane synthetic leather) |
| Base material | HIPS (High impact polystyrene) | HIPS (High impact polystyrene) |
| Back side material | - | Adhesive Layer |
| Material thickness mm | 1,5 mm | 1,7 mm |
| Max. relief height in mm | 1,5 mm | 1,7 mm |
| Temperature stability in °C | up to 50 °C | up to 50 °C |
| Wet room suitability | Good wet room suitability | Good wet room suitability |
| Rolled packable | Rolled with decor side outward, max. 3 pcs/box. Box size: 480x480 mm. After receipt, lay the rolled goods flat at room temperature for approximately 24 hours and, if necessary, apply additional weight. | |
| Smallest bending radius | 150 mm | 150 mm |
| Weight in kg / piece | 3,2 | 3,6 |
| Pattern Gradient | Please consider the design course | Please consider the design course |
| Flammability | EN 13501-1 Classification E | EN 13501-1 Classification E |
| Machine-related dimensional and angle tolerances | +/- 2.0 mm in relation to 1,000 mm | +/- 2.0 mm in relation to 1,000 mm |
| Temperature-related dimensional deviations | +/- 0.7 mm per 1,000 mm at a temperature change of 10°C | +/- 0.7 mm per 1,000 mm at a temperature change of 10°C |
| Protection foil | The product is delivered with a protective film. | The product is delivered with a protective film. |
| GTIN-Code | 9,00258E+12 | 9,00258E+12 |
| Customs tariff number | 39219060 | 39199080 |
Processing
| Processing | Non Adhesive (NA) | Self Adhesive (SA) |
|---|---|---|
| Cutting | - | - |
| Punching | - | - |
| Drilling | - | - |
| Sawing | - | - |
| Milling | - | - |
| Laser cutting | - | - |
| Hot bending |
Heat the SIBU DESIGN sheets from the backside
for both internal and external angles.
Guideline values: wire temperature approx. 200°C, heating time approx. 6–17 seconds, depending on the surface material and the bending tool. External angles (decor side outward) are possible. Internal angles (decor side inward) are also possible, but wrinkles may appear along the internal angle. |
|
| PVA compressible | - | - |
Extra equipment
| Extra equipment | Non Adhesive (NA) | Self Adhesive (SA) |
|---|---|---|
| Special formats | On request | On request |
| Further thicknesses | - | - |
| Cuttings | - | - |
| Magnetic available | Yes (from 3 sheets) | - |
| PVA treatment orderable | Please let us know when ordering | - |
| Special colors | - | - |
| Further variants | SIBUGLAS | SIBUGLAS |
| EN13501-1 Flammability orderable | - | - |
| ASTM E84 Flammability orderable | - | - |
Accessories
| Accessories | Non Adhesive (NA) | Self Adhesive (SA) |
|---|---|---|
| Glue recommendation | Putty adhesive with toothed spatula A2 | Not necessary |
| Matching Edges | - | - |
| Matching Profiles | - | - |
| Balance Sheet | HIPS white grained (Item no. 25877), 2610x1010 mm | Not necessary |
Cleaning
Do not use abrasive cleaners, solvent cleaners or pure alcohol! Clean leather surfaces using standard liquid soap, then remove the soap with a damp cloth.
Additional Info
Color variations are possible due to the manufacturing process and are not grounds for complaint.
