Description
Product characteristics
| Product characteristic | Non Adhesive (NA) | Self Adhesive (SA) |
|---|---|---|
| Item number | 19329 | 19340 |
| Format | 2600x1000x2,1 mm | 2600x1000x2,3 mm |
| Surface material = Base material | PMMA AR+Polymethyl methacrylate with anti-scratch coating | PMMA AR+Polymethyl methacrylate with anti-scratch coating |
| Back side material | PaperPaper | Paper & gluePaper & adhesive layer |
| Material thickness mm | 2,1 mm | 2,3 mm |
| Max. relief height in mm | 2,1 mm | 2,3 mm |
| Temperature stability in °C | up to 50 °C | up to 50 °C |
| Wet room suitability | Good wet room suitability | Good wet room suitability |
| Abrasion Resistance | Scratch resistant | Scratch resistant |
| Rolled packable | - | - |
| Smallest bending radius | 1000 mm | 1000 mm |
| Weight in kg / piece | 7 | 7,4 |
| Pattern Gradient | Please consider the design course | Please consider the design course |
| Flammability | EN 13501-1 (E) EN 13501-1 Classification E | EN 13501-1 (E) EN 13501-1 Classification E |
| Machine-related dimensional and angle tolerances | +/- 2.0 mm in relation to 1,000 mm | +/- 2.0 mm in relation to 1,000 mm |
| Temperature-related dimensional deviations | +/- 0.7mm to 1,000 mm at temperatur change of 10°C | +/- 0.7mm to 1,000 mm at temperatur change of 10°C |
| Protection foil | ||
| GTIN-Code | 9,00258E+12 | 9,00258E+12 |
| Customs tariff number | 39219060 | 39199080 |
Processing
| Processing | Non Adhesive (NA) | Self Adhesive (SA) |
|---|---|---|
| Cutting | - | - |
| Punching | - | - |
| Drilling | - | - |
| Sawing | Yes supported by a panel | Yes supported by a panel |
| Milling | Yes supported by a panel | Yes supported by a panel |
| Laser cutting | - | - |
| Hot bending | - | - |
| PVA compressible | - | - |
| Digital printing | Samples available for printing tests | Samples available for printing tests |
| Screen printing | Samples available for printing tests | Samples available for printing tests |
Extra equipment
| Extra equipment | Non Adhesive (NA) | Self Adhesive (SA) |
|---|---|---|
| Special formats | On request | On request |
| Further thicknesses | - | - |
| Cuttings | - | - |
| Magnetic available | Yes (from 3 sheets) | - |
| PVA treatment orderable | - | - |
| Special colors | - | - |
| Further variants | OPACO-LINE | OPACO-LINE |
| EN13501-1 Flammability orderable | - | - |
| ASTM E84 Flammability orderable | - | - |
Accessories
| Accessories | Non Adhesive (NA) | Self Adhesive (SA) |
|---|---|---|
| Glue recommendation | Putty adhesive with toothed spatula A2 | not necessary |
| Matching Edges | - | - |
| Matching Profiles | - | - |
| Balance Sheet | PMMA White grained (Itemno. 25879) 2600x1010 mm | not necessary |
Cleaning
Do not use abrasive cleaners, solvent cleaners or pure alcohol! In case of light dirt by means of soft cleaning cloth (it should be free of dust and free of dirt). In case of heavy dirt by means of standard plastic or window cleaner (spray cleaners not onto the material surface, but sparingly onto the cleaning cloth).
